产品展示   当前位置 --> 网站首页 --> 产品展示
名称:ESD-粘尘棒 型号:HOST-2019-ESDC007

ESD-粘尘棒说明书



品名:ESD-粘尘棒

品牌:昊斯特

型号:HOST-2019-ESDC007

原料:特别研发的专用胶水(颜色可选:蓝、绿、白、黑、黄、透明等);

杆子:纸质、亚克力、ABCPC、金属等

产品规格:

175mm

2150mm

   图片包含 室内, 餐桌, 柜台, 地板
描述已自动生成  图片包含 地面, 建筑物, 户外, 地板
描述已自动生成

图片包含 室内, 照片
描述已自动生成

特性

1、永久粘性,不挥发,不拉丝,不留痕。

2、柔软,有韧性,良好的灵活性和操作感。

3、环保,无刺激性气味,不会对接触者产生任何伤害。

4、对产品的电气性和外观有很好的保护。

5、不含硅



用途:
1、清洁激光头、手机摄像头、镜头、微粒。

2、清除(10—5000级无尘室)LED/LCD表面particle

3、清洁LENS表面遗留的玻璃/塑胶碎屑()

4、粘去半导体生产光盘/磁盘表面的脏点脏污。
5
、清除COB工艺裸露镀膜SENSORMicron lens微尘粒,



操作作业指示

1、去除外包装,清洁胶棒外包装进入风淋室再进无尘室。

2、作业前先做好5S准备,台面、地面、设备、椅子、手套、工具、夹具、托盘等并用显微镜检查。

3、用镊子从托盘轻轻夹起,带胶端不可与物体接触,以免污染,用手拿住另一端准备操作。

4、胶棒在显微镜或软件下对准尘点位置,保持60°~90°角度轻轻粘取,不可大力,以免刮伤、压伤SENSOR

5、使用时要拿稳,切勿来回抖动,不可在产品上移动摩擦,以免划伤。

6、每支胶棒擦拭产品最多不超过十五到二十次,以免造成二次污染。

7、使用过的胶棒要远离工作区,与干净胶棒分开。



 注意事项:

1、平面或向上,严禁侧放或颠倒。

2. 避光保存。

3. 保存温度30°以下。

4. 保存期三个月。



案例图片:

/var/folders/rx/n0_bm5rs1c1dvhsynd8vls6w0000gn/T/com.microsoft.Word/WebArchiveCopyPasteTempFiles/O1CN01ZUUQCP1r16c0FoKYx_!!329845570.jpg/var/folders/rx/n0_bm5rs1c1dvhsynd8vls6w0000gn/T/com.microsoft.Word/WebArchiveCopyPasteTempFiles/O1CN01OzaYo81r16c0HSdgV_!!329845570.jpg

/var/folders/rx/n0_bm5rs1c1dvhsynd8vls6w0000gn/T/com.microsoft.Word/WebArchiveCopyPasteTempFiles/O1CN01h4PACL1r16c1WTBRW_!!329845570.jpg

/var/folders/rx/n0_bm5rs1c1dvhsynd8vls6w0000gn/T/com.microsoft.Word/WebArchiveCopyPasteTempFiles/O1CN01puN8aX1r16bzAQvqS_!!329845570.jpg

包装规格:

130支一盒

23000支一箱

包装图片:



ESD- Tacky Stick



Model: HOST-2019-ESDC007

Material: PC handle with Polymer Tacky Tip

2 length available

1、         75 mm long PC handle

2、         150 mm long PC handle

Characteristics

·      Tacky tip to pick up loose particles or fibers

·      Soft, flexible tacky tip that leaves no stains on surfaces

·      Non- volatile and no unpleasant smell

·      No harm when contact with skin

·      Silicone free product



Applications:

1.    Effective in removing particles or foreign material on laser head, mobile phone or camera lens, or any sensitive optical lens

2.    Remove particles or foreign material from LED/ LCD surface

3.    Remove particles or foreign material from surface of semi-conductor wafer fab disk



Usage Procedures:

1.    Remove the outer packaging before channeling the packaging trays with Tacky Stick through the air shower, into the control or clean room.

2.    Perform 5S house- keeping on the work bench, chairs, flooring, equipment, tools and fixtures, etc

3.    Gently lift the Tacky Stick from the end without the Sticky Tip. Do not contact the Sticky Tip with any surfaces to avoid cross contamination. It is ready to be used.

4.    Adjust the Sticky Tip to the location of the dust or foreign particles to be removed, lightly placed the Sticky Tip onto the target and lift it up. Avoid excessive force or slide the Sticky Tip along the surfaces, especially on sensitive and fragile component.

5.    Each Sticky Stick can be used approximately 10-15 times, depending on amount of debris removed from surfaces.

6.    Discard the used Sticky Stick to a disposal box and do not mix with new parts.

Packaging Standards

130 pcs per tray

23000 pcs per box
